RIEGLER flow meter "FLUX 0", 0 ? 50 Nl/min, Ø 8 mm, 4 ? 20 mA
Typennummer: 9000958A2
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Flow meter "FLUX 0" made of technopolymer, for pressure measurement, max. 8 bar - Type 9000958A2
The RIEGLER flow meter "FLUX 0", 0 ? 50 Nl/min, Ø 8 mm, 4 ? 20 mA measures pressure or temperature reliably and precisely. The housing is made of technopolymer. The operating pressure range is -0.9 bar to 8 bar. The temperature range is between 0 °C and 50 °C. Connection thread plug connection Ø 8 mm - suitable for common industry standards. Suitable for filtered, non-lubricated compressed air and neutral gases. Protection class IP 40. Reliable measured values for safe processes.
Field of application
Typical areas of application: Pressure monitoring and temperature control.
| Function | Flow meter/switch, pressure gauge, pressure switch |
| Connection | Push-in connection Ø 8 mm |
| WiFi | without |
| Supply voltage | 12 bis 24 +/-10 % V DC |
| Compatible with app | no |
| IO-Link | without |
| Flow measuring range min. | 0 Nl/min |
| Flow measuring range max. | 50 Nl/min |
| Pressure sensor | with |
| Operating voltage min. | 10.8 V DC |
| Operating voltage max. | 26.4 V DC |
| Scope of delivery | Plug with 2 m cable |
| Analogue output | 4 - 20 mA |
| Output of the measured values | via cable and display |
| Digital output | 2 PNP |
| Hysteresis | adjustable |
| Flow direction | unidirectional |
| Display | with |
| Operating pressure min. | -0.9 bar |
| Measuring system | thermal |
| Series | FLUX 0 |
| Medium | filtered, unlubricated compressed air and neutral gases |
| REACH Info | contains SVHC substance |
| RoHS material information | Rohs compliant |
| REACH SVHC1 Substance Name | Lead |
| Housing | Technopolymer |
| BG | 0 |
| Temperature range min. | 0 °C |
| Inlet pressure max. | 10 bar |
| Temperature range max. | 50 °C |
| B | 52 mm |
| CAS No. SVHC 1 | 7439-92-1 |
| Max. operating pressure | 8 bar |
| A | 83 mm |
| Protection class | IP 40 |
| Class name | MAX |
