RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 1, G 3/8
Typennummer: FU 892-M
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Active charcoal filter »FUTURA« with metal container and viewing tube, 0.005 mg/m³, Size 1, G 3/8, Input pressure 0 - 16 bar
| Inlet pressure min. | 0 bar |
| Inlet pressure max. | 16 bar |
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | Compressed air, neutral gases |
| Housing | PA66 GF60 |
| Connection thread | Material zinc die-cast |
| Flow rate measurement | at P<sub>2</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 0.2 bar |
| Series | FUTURA |
| Container | Metal container with sight tube |
| Filter element | Activated carbon |
| Residual oil content | 0.005 mg/m³ |
| Thread | G 3/8 |
| Flow rate | 470 l/min |
| BG | 1 |
| A | 52 mm |
| B | 158 mm |
| C | 34 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Class name | MAX |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[156646] RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 1, G 1/4](/web/image/product.template/213382/image_128/%5B156646%5D%20RIEGLER%20Active%20charcoal%20filter%20%C2%BBFUTURA%C2%AB%2C%20Metal%20container%2C%20Size%201%2C%20G%201-4?unique=e1f1216)
|
Typennummer: FU 891-M |
84.29 € | |
![[139513] RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 2, G 1/2](/web/image/product.template/207993/image_128/%5B139513%5D%20RIEGLER%20Active%20charcoal%20filter%20%C2%BBFUTURA%C2%AB%2C%20Metal%20container%2C%20Size%202%2C%20G%201-2?unique=c0e00a5)
|
Type number: FU 894-M |
140.55 € | |
![[139512] RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 2, G 3/8](/web/image/product.template/207992/image_128/%5B139512%5D%20RIEGLER%20Active%20charcoal%20filter%20%C2%BBFUTURA%C2%AB%2C%20Metal%20container%2C%20Size%202%2C%20G%203-8?unique=c2cb998)
|
Type number: FU 893-M |
140.55 € | |
![[156649] RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 4, G 1](/web/image/product.template/213385/image_128/%5B156649%5D%20RIEGLER%20Active%20charcoal%20filter%20%C2%BBFUTURA%C2%AB%2C%20Metal%20container%2C%20Size%204%2C%20G%201?unique=f6e5036)
|
Typennummer: FU 6191-M |
174.63 € | |
![[156648] RIEGLER Active charcoal filter »FUTURA«, Metal container, Size 4, G 3/4](/web/image/product.template/213384/image_128/%5B156648%5D%20RIEGLER%20Active%20charcoal%20filter%20%C2%BBFUTURA%C2%AB%2C%20Metal%20container%2C%20Size%204%2C%20G%203-4?unique=9e364e5)
|
