AIRpipe reduction connection, DN80-DN63
AIRpipe specializes in providing high-performance piping systems for compressed air and noble gases. Their products are known for their durability, reducing operating costs, and increasing productivity
AIRpipe Reduction connection, DN80-DN63 - Compressed air piping system
The AIRpipe reduction connection, DN80-DN63 is a compressed air reducer for the transition between different pipe diameters. Full cross-section without internal constriction. Clamp connection with convex flared ring and concentric seal - leakage-free even with vibrations.
Technical data
- Function: Compressed air reducer - leak-free nominal diameter transition
- Material: Powder-coated cast aluminum, corrosion-free, recyclable
- Operating pressure: Up to 15 bar (-20°C to +80°C), vacuum up to 1 mbar
Field of application
Compressed air transition between different pipe sizes. Reusable and modularly expandable.
| DN | 80-63 |
