Filtration Group EcoParts Filter element for CJC Filter B 15/25, BG 15/25, BLA 15/25
Manufacturer type designation: C 1525 DN 2 003 WS
Filtration fineness: 3 µm
Filter material: WS
Filtration Group's filtration and separation solutions ensure success, guarantee trouble-free plant operation, promote clean working environments and protect valuable capital goods
| Mounting diameter (mm) | 20.5 |
| Outer diameter (mm) | 151 |
| Differential pressure (bar) | 10 |
| Element type | EcoParts |
| End disc material | Plastic end disk PA |
| Filter fineness (micrometres) | 3 |
| Filter material | Glass fiber (WS) |
| Height (mm) | 219 |
| Inner diameter (mm) | 24 |
| Medium | Hydraulic oil |
| Original manufacturer | CJC |
| Original manufacturer product number | B15/25 BG15/25 BLA15/25 |
| Seal material | NBR |
| Compatible with SF filter | HY 15832 |
