FILTREC replacement filter element for Hydac 90512MA20BN
Filtrec has stood for excellence in filtration since 1991. As a family-run company based in Italy, Filtrec develops high-performance hydraulic and process filters for industrial applications - worldwide, innovative and reliable
Precisely fitting replacement filter element for Hydac 90512MA20BN - Quality from Italy
This FILTREC replacement filter element with glass fiber filter medium, 20µm filter fineness, NBR seal and max. 12 bar differential pressure is the high-quality alternative to the Hydac 90512MA20BN. Manufactured in Italy according to international ISO standards. Further technical data can be found in the "Technical data" tab.
| Field of application | Hydraulics |
| Max. Operating pressure (bar) | 24 |
| max. differential pressure (bar) | 12 |
| Outer diameter (mm) | 117 |
| Height (mm) | 297.5 |
| Connection thread | 1"3/4-12 UN 2B |
| Filter material | Glass fiber |
| Filter fineness (micrometres) | 20 |
| Filter fineness c (micrometer) | ß22=1000 |
| Seal material | NBR |
| A | 117 mm |
| B | 1"3/4-12 UN 2B |
| C | 2975 |
