RIEGLER Mist oiler »multifix-mini« Metal container, metal drip cap, G 1/4
Type number: L 06 M
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Mist lubricator "multifix-mini" made of die-cast zinc, for compressed air treatment, G 1/4 - type L 06 M
The RIEGLER mist lubricator "multifix-mini", with metal container, BG 0, G 1/4 doses precise quantities of oil into the compressed air flow and automatically lubricates pneumatic consumers. The housing is made of die-cast zinc with NBR seals. The maximum inlet pressure is 20 bar. The permissible medium temperature is between -10 °C and 60 °C. Connection thread G 1/4 - suitable for common industry standards. The flow rate is 1150 l/min (at P2 = 6 bar and pressure drop Δp = 1 bar). Tank made of metal container. Automatic lubrication extends the service life of moving parts.
Field of application
Typical areas of application: Lubrication of pneumatic cylinders, valves and pneumatic tools.
| Inlet pressure max. | 20 bar |
| Housing | Zinc die casting |
| Sealing material | NBR |
| Flow rate measurement | at P<sub>2</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Series | multifix-mini |
| Container | Metal container |
| Dropper attachment | Zinc-glass-NBR |
| Oil grade | CL 32 according to DIN 51517-ISO VG 32 |
| Medium temperature min. | -10 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -10 °C |
| Ambient temperature max. | 60 °C |
| Thread | G 1/4 |
| Flow rate | 1150 l/min |
| DN | 5 |
| BG | 0 |
| A | 40 mm |
| B | 147.6 mm |
| C | 62.6 mm |
| D | 85 mm |
| Class name | PLUS |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[100389] RIEGLER Mist oiler »multifix-mini« Metal container, metal drip cap, G 1/8](/web/image/product.template/139823/image_128/%5B100389%5D%20RIEGLER%20Mist%20oiler%20%C2%BBmultifix-mini%C2%AB%20Metal%20container%2C%20metal%20drip%20cap%2C%20G%201-8?unique=5287e0b)
|
