RIEGLER Standard pressure gauge, CrNi steel, G 1/4, 0 - 6 bar, Ø 50
Type number: 4165
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
102443EAN :
4047322276474Category :
Stainless Steel Pressure GaugesWeight :
0.09 kgRIEGLER Standard mano made of stainless steel, for pressure measurement, G 1/4 - Type 4165
The RIEGLER standard manometer, stainless steel, G 1/4 rear center, 0 - 6.0 bar, Ø 50 indicates the current system pressure reliably and precisely. The housing is made of stainless steel. The permissible medium temperature is between -40 °C and 100 °C. G 1/4 connection thread - suitable for common industry standards. Reliable pressure indicator for safe system control.
Field of application
Typical areas of application: Pressure monitoring in compressed air, hydraulic and process systems.
| Medium temperature min. | -40 °C |
| Medium temperature max. | 100 °C |
| Ambient temperature min. | -40 °C |
| Ambient temperature max. | 60 °C |
| Material | CrNi steel |
| Type | 131.11 |
| Viewing window | Polycarbonate |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 6 |
| Measuring range min. psi | 0 |
| Diameter | 50 mm |
| Graduation value in the bar range | 0.2 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/4 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| Measuring range max. psi | 86 |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 45414 |
| Connection position | rear, centric |
| Class name | STAINLESS STEEL |
| Process connection material | CrNi steel |
