RIEGLER Shut-off valve "SYNTESI", pneumatic, BG1, G 1/8
Type number: 5611V201
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Shut-off valve "SYNTESI" made of technopolymer, for compressed air treatment - Type 5611V201
The RIEGLER shut-off valve "SYNTESI", pneumatic, BG1, G 1/8 adds additional modular functions to maintenance systems. The housing is made of technopolymer. The maximum inlet pressure is 15 bar. The temperature range is between -10 °C and 50 °C. Suitable for compressed air or other neutral gases. Seamless integration into existing systems.
Field of application
Typical areas of application: Modular compressed air treatment lines.
| Inlet pressure max. | 15 bar |
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | Compressed air or other neutral gases |
| Housing | Technopolymer |
| Control pressure min. | 3 bar |
| Control pressure max. | 10 bar |
| BG | 1 |
| Input connection | G 1/8 |
| Output connection | G 1/8 |
| A | 42 mm |
| B | 66 mm |
| Exhaust air | G 1/8 |
| Flow 1 | 800 Nl/min |
| Flow 2 | 1100 Nl/min |
| Flow rate measurement 1 | P2 = 6.3 bar and pressure drop Δp = 0.5 bar |
| Flow rate measurement 2 | P<sub>2</sub> = 6.3 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Class name | PLUS |
| Series | Syntesi |
| F | 32.2 mm |
| Vent flow rate at 6.3 | 500 Nl/min |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[144865] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG1, G 1/4](/web/image/product.template/279995/image_128/%5B144865%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG1%2C%20G%201-4?unique=4e0fc34)
|
Type number: 5612V202 |
60.55 € | |
![[144866] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG1, G 3/8](/web/image/product.template/279996/image_128/%5B144866%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG1%2C%20G%203-8?unique=c928697)
|
Type number: 5613V203 |
60.55 € | |
![[144863] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG1, without sockets](/web/image/product.template/279993/image_128/%5B144863%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG1%2C%20without%20sockets?unique=0a2ab9a)
|
Type number: 5610V200 |
58.32 € | |
![[144871] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG2, G 1](/web/image/product.template/280001/image_128/%5B144871%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG2%2C%20G%201?unique=c71d90d)
|
Type number: 5626V206 |
106.62 € | |
![[144869] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG2, G 1/2](/web/image/product.template/279999/image_128/%5B144869%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG2%2C%20G%201-2?unique=9628aa7)
|
Type number: 5624V204 |
97.91 € | |
![[144870] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG2, G 3/4](/web/image/product.template/280000/image_128/%5B144870%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG2%2C%20G%203-4?unique=43e77cd)
|
Type number: 5625V205 |
106.62 € | |
![[144868] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG2, G 3/8](/web/image/product.template/279998/image_128/%5B144868%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG2%2C%20G%203-8?unique=5e757e3)
|
Type number: 5623V203 |
97.91 € | |
![[144867] RIEGLER Shut-off valve "SYNTESI", pneumatic, BG2, without sockets](/web/image/product.template/279997/image_128/%5B144867%5D%20RIEGLER%20Shut-off%20valve%20%22SYNTESI%22%2C%20pneumatic%2C%20BG2%2C%20without%20sockets?unique=b50c928)
|
