RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NO, 110 V AC

Price:

63.72 €

RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NO, 24 V AC
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NO, 24 V AC
63.72 € 63.72 €
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NC, 12 V DC
RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NC, 12 V DC
63.72 € 63.72 €

RIEGLER 3/2-way valve, electropneumatic, monostable, G 1/8, NO, 110 V AC

https://www.filcom-technik.de/web/image/product.template/275774/image_1920?unique=71874f8

Type number: 39.902

EAN: 4047322773652

63.72 € 63.72 EUR 63.72 € VAT Included

82.39 € VAT Included


  • Brand

This combination does not exist.

from 110 € free shipping Details shipping costs

Riegler

Riegler

RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.


Product no. :

145850

EAN :

4047322773652

Weight :

0.29 kg

3/2-way valve, electropneumatic, monostable, G 1/8, NO, 110 V AC, 50/60 Hz, p = 2.5 ... 10 bar, aluminum
Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material NBR
Series Valves Series 70
Operating pressure min. 2.5 bar
Max. operating pressure 10 bar
Medium temperature min. -10 °C
Medium temperature max. 60 °C
Ambient temperature min. -10 °C
Ambient temperature max. 50 °C
Manual override resting
DN 5
Function 3/2 NO
Actuation monostable
Symbol 32
Connection G 1/8
Flow_1 400 Nl/min
Flow_2 550 Nl/min
Class name PLUS
Tension 110 V, 50/60 Hz
Flow rate measurement 1 Flow rate at 6 bar and Δp 0.5 bar
Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar
