KAESER Reciprocating compressor model PREMIUM CAR 150-2/16 W
Suction capacity: 150 l/min | Maximum overpressure: 25 bar | Pressure tank: 16 l | Electrical connection: 230 V
KAESER KOMPRESSOREN, a family-owned company, has been one of the world's leading manufacturers and suppliers of compressed air products and services since 1919
Product no. :
1.1853.1Category :
PREMIUM CAR (construction site)Weight :
87.00 kgDelivery area :
GermanyMobile high-pressure piston compressor for the construction site - 25 bar operating pressure
The KAESER PREMIUM CAR 150-2/16 is a portable piston compressor that has been specially designed for tough construction site use. This KAESER Quality product impresses with its robust frame construction: The construction site compressor is tilt-proof and can be easily transported around the construction site thanks to its sturdy wheels.
Technical highlights
- Suction capacity: 150 l/min - sufficient compressed air for demanding construction site work.
- Maximum overpressure: 25 bar - reliable operating pressure for all standard pneumatic tools.
- Compressed air tank: 16 liter tank - for a constant supply of compressed air on the construction site.
- Electrical connection: 230V alternating current - for flexible use at any household socket.
Quality & structure
- Made in Germany: Manufactured at the KAESER production center in Coburg - highest quality and reliability.
- Stainless steel valves: Corrosion-free valves with heat-dissipating stroke limiter for tight closing and long service life.
- High-performance fluid: Filled with temperature-resistant special fluid as standard - almost no oil carbon, up to 1,000 h change interval.
- CE-certified: With LwA and CE mark in accordance with legal requirements. Type-tested.
- Tilt-proof frame: Robust steel frame construction with wheels for safe transportation on the construction site.
Typical areas of application
- Construction site: Mobile air compressor for daily use on construction sites with pneumatic nailers and chipping hammers.
- High pressure applications: Ideal for applications that require a high operating pressure of up to 25 bar.
- Mobile use: Compact design and stable wheels for easy transportation on site.
| Volume flow at 20 bar (l/min) | 103 |
| Suction volume flow (l/min) | 150 |
| Max. Overpressure (bar) | 25 |
| Rated power drive motor (kW) | 2,2 |
| Number of cylinders | 2 |
| Nominal synchronous speed (1/min) | 1500 |
| Volume of compressed air tank (litres) | 16 |
| Emission sound pressure level (dB(A)) | 70 |
| Sound power level (dB(A)) | 97 |
| Hose connection (mm) | 2 x G 1/4 |
| Electrical supply | 230 V / 1 Ph / 50 Hz |
| Width (mm) | 560 |
| Depth (mm) | 870 |
| Height (mm) | 590 |
| Weight (kg) | 87 |
| Model range - piston compressors | Premium Car |
| Hose reel attached | NO |
| Design | mobile |
