RIEGLER Micrometre pressure gauge, radial bottom G 1/2, -1/+0.6 bar, Ø160
Type number: 1158/1
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Fine pressure gauge, radial bottom connection, G 1/2, model 312.20, grade 0.6, scale graduation 0.010, range no. -1 / +0.6 bar, Ø 160
| Housing | CrNi steel |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 80 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | 312.20 |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Instrument flat glass |
| Measuring range min. bar | -1 |
| Measuring range max. bar | 0.6 |
| Diameter | 160 mm |
| Graduation value in the bar range | 0.01 bar |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Quality class | 0.6 |
| Lower / Upper measuring range limit | Vacuum/overpressure |
| Ring | CrNi steel |
| Connection position | radial bottom |
| Class name | MAX |
| Process connection material | Copper alloy |
