RIEGLER Contact pressure gauge, radial bottom, G 1/2, 0 - 40 bar, Ø 100
Type number: 2207
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Contact pressure gauge made of stainless steel 1.4301, for pressure measurement, G 1/2 - type 2207
The RIEGLER contact pressure gauge, G 1/2 radial bottom, measuring range 0-40.0 bar, Ø 100 indicates the current system pressure reliably and precisely. The housing is made of stainless steel 1.4301. The permissible medium temperature is between -20 °C and 80 °C. G 1/2 connection thread - suitable for common industry standards. Reliable pressure display for safe system control.
Field of application
Typical areas of application: Pressure monitoring in compressed air, hydraulic and process systems.
| Housing | Stainless steel 1.4301 |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 80 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Type | PGS21 |
| Measuring element | Copper alloy |
| Pointer movement | Copper alloy |
| Viewing window | Polycarbonate |
| Rated operating voltage Ueff max. | 250 V |
| Switching capacity max. | 30 W / 50 VA |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 40 |
| Diameter | 100 mm |
| Graduation value in the bar range | 1 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| Connection | G 1/2 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Quality class | 1 |
| Lower / Upper measuring range limit | Overpressure |
| Ring | Stainless steel 1.4301 |
| Connection position | radial bottom |
| Class name | MAX |
| Process connection material | Copper alloy |
