RIEGLER Block valve pressure gauge, Bushing - taps, bright brass, G 1/2
Type number: 9009/M
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
102649EAN :
4047322122771Category :
Accessories for Pressure GaugesWeight :
0.27 kgPressure gauge stopcock, socket - spigot, made of bare brass, G 1/2, PN 25 bar, SW 27, max. 50 °C
| Temperature range max. | 50 °C |
| Housing | Brass bright |
| Area of application | for all pressure gauges with flat sealing ring to DIN 16258 |
| Hand lever | Plastic |
| Thread | G 1/2 |
| SW | 27 mm |
| PN | 25 bar |
| Regulation | DIN 16261-B |
| Execution | Socket / spigot |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[102651] RIEGLER Block valve pressure gauge, Bushing - taps, bright brass, G 1/2](/web/image/product.template/170623/image_128/%5B102651%5D%20RIEGLER%20Block%20valve%20pressure%20gauge%2C%20Bushing%20-%20taps%2C%20bright%20brass%2C%20G%201-2?unique=a84f216)
|
Type number: 9010/60 |
26.31 € | |
![[102647] RIEGLER Block valve pressure gauge, Bushing - taps, bright brass, G 1/4](/web/image/product.template/170619/image_128/%5B102647%5D%20RIEGLER%20Block%20valve%20pressure%20gauge%2C%20Bushing%20-%20taps%2C%20bright%20brass%2C%20G%201-4?unique=34bde22)
|
Type number: 9007 |
10.75 € | |
![[102648] RIEGLER Block valve pressure gauge, Bushing - taps, bright brass, G 3/8](/web/image/product.template/170620/image_128/%5B102648%5D%20RIEGLER%20Block%20valve%20pressure%20gauge%2C%20Bushing%20-%20taps%2C%20bright%20brass%2C%20G%203-8?unique=04b2b3d)
|
Type number: 9008 |
12.91 € | |
![[102650] RIEGLER Block valve pressure gauge, Bushing-taps, stainless steel, G 1/2](/web/image/product.template/170622/image_128/%5B102650%5D%20RIEGLER%20Block%20valve%20pressure%20gauge%2C%20Bushing-taps%2C%20stainless%20steel%2C%20G%201-2?unique=d34098d)
|
Type number: 9009/ES |
80.31 € | |
