RIEGLER Impact reducer for pressure gauge, G 1/2, PN 400 bar, steel
Type number: 9018/S
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
102683EAN :
4047322122931Category :
Accessories for Pressure GaugesWeight :
0.20 kgRIEGLER Shock absorber for pressure gauge made of steel, G 1/2 - Type 9018/S
The RIEGLER shock reducer for pressure gauges, G 1/2, PN 400 bar, made of steel adds protection and connection functions to pressure gauges. The housing is made of steel with NBR seals. The temperature range is between -10 °C and 120 °C. G 1/2 connection thread - suitable for common industry standards. Protection and functional extension for pressure gauges.
Field of application
Typical areas of application: Professional pressure gauge installation.
| Temperature range min. | -10 °C |
| Temperature range max. | 120 °C |
| Housing | Steel |
| Sealing material | NBR |
| Thread | G 1/2 |
| SW | 27 mm |
| PN | 400 bar |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Screw plug | Steel |
| Regulating spindle | Stainless steel 1.4404 |
