RIEGLER Coaxial valve pneumat. actuated, single-acting NC, NBR, Rp 1
Type number: 351.944
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Shut-off valve, pneumatically operated, nickel-plated brass, for industrial systems, max. 10 bar - Type 351.944
The RIEGLER pneumatically operated shut-off valve, single-walled, NC, MS, nickel-plated, Rp. NC, MS nickel-plated, NBR, Rp 1 controls or blocks the flow of media in industrial pipelines. The housing is made of nickel-plated brass with NBR seals. Designed for a maximum operating pressure of 10 bar. The operating temperature is between -20 °C and 80 °C. Connection thread Rp 1 - suitable for common industrial standards. Reliable media control.
Field of application
Typical areas of application: Compressed air, gases and liquids.
| Housing | Nickel-plated brass |
| Sealing material | NBR |
| Max. operating pressure | 10 bar |
| Installation position | any |
| Interior parts | Nickel-plated brass |
| Control pressure min. | 4.2 bar |
| Control pressure max. | 8 bar |
| Operating temperature min. | -20 °C |
| Operating temperature max. | 80 °C |
| Spring | Stainless steel |
| Thread | Rp 1 |
| DN | 25 |
| L | 143 mm |
| H | 69 mm |
| Execution | single-acting - spring-closing |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| Connection | NAMUR interface, direct: 2 x G 1/8 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW614N |
| Class name | EASY |
| REACH SVHC2 Substance Name | Octamethylcyclotetrasiloxane (D4) |
| REACH SVHC3 Substance Name | Decamethylcyclopentasiloxane (D5) |
| REACH SVHC4 Substance Name | Dodecamethylcyclohexasiloxane (D6) |
