RIEGLER Angled threaded connector 90°, M8x0.75 ET tapered, Hose 9 mm
Type number: 290.930
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Elbow threaded nozzle 90° made of brass 2.0401, for compressed air supply - type 290.930
The RIEGLER elbow threaded nozzle 90°, M8x0.75 male, hose connection 9 mm connects temperature control circuits quickly and drip-free. The housing is made of brass 2.0401. Hose connection 9 mm. Drip-free disconnection for a clean working environment.
Field of application
Typical areas of application: Toolmaking and injection molding technology.
| Material | Brass 2.0401 |
| Length | 27 mm |
| Hose connection | 9 mm |
| REACH SVHC1 Substance Name | Lead |
| CAS No. SVHC 1 | 7439-92-1 |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| External thread | M8x0.75 keg |
| RoHS Article of the Directive | Article 4, paragraph 1, Annex 3 |
| Share of SVHC substance in % for RoHS | 0.04 |
| Exception | 6c |
| REACH Info | contains SVHC substance |
| Share of SVHC SCIP | >= 1.0% w/w and < 10.0% w/w |
| Proportion of SVHC substance in SCIP | >= 0.1 % in w/w |
| Material identification | CW617N |
