RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-400bar/6000 psi
Type number: 715-CDE
EAN: 4047322176828
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
116316EAN :
4047322176828Category :
Glycerine-Filled Pressure GaugesWeight :
0.24 kgGlycerin mano. "pressure line", stainless steel housing, radial bottom connection, G 1/4, grade 1.6, measuring range 0-400.0 bar/6000 psi, Ø 63
| Housing | Stainless steel 1.4301 |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Brass |
| Pointer movement | Brass |
| Viewing window | Glass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 400 |
| Diameter | 63 mm |
| Graduation value in the bar range | 10 bar |
| Execution | Bourdon tube pressure gauge with glycerine filling |
| Connection | G 1/4 |
| Quality class | 45444 |
| Connection position | radial bottom |
| Class name | EASY |
| Process connection material | Copper alloy |
