RIEGLER 5/3-way valve, electropneumatic, center-closed, G 1/8, 24 V AC

Type number: 517.53.18.CC.24A

117.39 € 117.39 EUR 117.39 € VAT Included

137.01 € VAT Included

Brand

This combination does not exist.

Add to Cart

from 110 € free shipping Details shipping costs

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

145867

EAN :

4047322773829

Category :

Valves Electropneumatically Operated

Weight :

0.32 kg

Description
Specifications

5/3-way valve, electropneumatic, center closed, G 1/8, 24 V AC, 50/60 Hz, p = 2.5 ? 10 bar, aluminum

Medium	Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material	NBR
Series	Valves Series 70
Operating pressure min.	2.5 bar
Max. operating pressure	10 bar
Medium temperature min.	-10 °C
Medium temperature max.	60 °C
Ambient temperature min.	-10 °C
Ambient temperature max.	50 °C
Manual override	resting
DN	5
Actuation	Center closed
Symbol	37
Connection	G 1/8
Flow 1	400 Nl/min
Flow 2	550 Nl/min
Class name	PLUS
Function	45356
Tension	24 V, 50/60 Hz
Flow rate measurement 1	Flow rate at 6 bar and Δp 0.5 bar
Flow rate measurement 2	Flow rate at 6 bar and Δp 1.0 bar

Maintenance, wear and spare parts

	Price
[145715] RIEGLER 5/3-way valve, electropneumatic, center closed, G 1/8 Type number: 7010022100	106.05 €	Add to cart
[117313] RIEGLER Device plug, 22 mm, type B Type number: 1920.9P	1.48 €	Add to cart
[118628] RIEGLER Solenoid coil, 22 mm x Ø 8 mm, 24 V AC, 50/60 Hz, 3.5 VA Type number: 400-514-01	9.87 €	Add to cart
