RIEGLER 5/2-way valve, elpn., ext. control air, bistable, G 3/8, 230 V AC
Typennummer: 517.52.38.E.B.230A
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
147289EAN :
4047322790154Category :
Valves Electropneumatically OperatedWeight :
0.01 kgRIEGLER 5/2-way valve for pneumatic control, max. 10 bar, G 3/8 - Type 517.52.38.E.B.230A
The RIEGLER 5/2-way valve, elpn., ext. control air, bistable, G 3/8, 230 V AC controls the direction of the compressed air flow for targeted movement sequences. with NBR seals. The operating pressure range is -0.99 bar to 10 bar. The permissible medium temperature is between -10 °C and 60 °C. Connection thread G 3/8 - suitable for common industry standards. Suitable for filtered compressed air with or without lubrication. If lubricated, then continuous. Operating voltage 230 V AC. Precise directional control for defined movement sequences.
Field of application
Typical areas of application: Pneumatic controls and mechanical engineering.
| Execution | electropneumatic |
| DN | 133 |
| Control air supply | external |
| Tension | 230 V AC |
| Symbol | 60 |
| Scope of delivery | with plug and coil |
| Frequency | 50/60 Hz |
| Series | Series 70 |
| Flow rate measurement 1 | Flow rate at 6 bar and ∆p 0.5 bar |
| Flow rate measurement 2 | Flow rate at 6 bar and Δp 1.0 bar |
| Flow 2 | 2150 Nl/min |
| Flow 1 | 1560 Nl/min |
| Actuation | bistable |
| Operating pressure min. | -0.99 bar |
| Ambient temperature min. | -10 °C |
| Medium temperature min. | -10 °C |
| Function | 5/2 |
| Control pressure max. | 10 bar |
| Max. operating pressure | 10 bar |
| Control pressure min. | 2.5 bar |
| Ambient temperature max. | 50 °C |
| Medium temperature max. | 60 °C |
| Pilot air connection | G 1/8 |
| Connection | G 3/8 |
| Medium | Filtered compressed air with or without lubrication. If lubricated, then continuous. |
| Sealing material | NBR |
| Class name | PLUS |
| Manual override | resting |
Maintenance, wear and spare parts
| Product | Price | ||
|---|---|---|---|
![[147127] RIEGLER 5/2-way valve, electropneumatic, ext. control air, bistable, G 3/8](/web/image/product.template/284069/image_128/%5B147127%5D%20RIEGLER%205-2-way%20valve%2C%20electropneumatic%2C%20ext.%20control%20air%2C%20bistable%2C%20G%203-8?unique=939c959)
|
Typennummer: 7040021600 |
113.70 € | |
![[117313] RIEGLER Device plug, 22 mm, type B](/web/image/product.template/274839/image_128/%5B117313%5D%20RIEGLER%20Device%20plug%2C%2022%20mm%2C%20type%20B?unique=4bd6d96)
|
Type number: 1920.9P |
1.48 € | |
![[118630] RIEGLER Solenoid coil, 22 mm x Ø 8 mm, 230 V AC, 50/60 Hz, 3.5 VA](/web/image/product.template/275046/image_128/%5B118630%5D%20RIEGLER%20Solenoid%20coil%2C%2022%20mm%20x%20%C3%98%208%20mm%2C%20230%20V%20AC%2C%2050-60%20Hz%2C%203.5%20VA?unique=bd405eb)
|
Type number: 400-514-17 |
9.87 € | |
