RIEGLER 2x3/2-way valve, electropneumatic, monostable, G 1/4, NO, 24 V DC
Typennummer: 517.232.14.NO.24D
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Product no. :
147364EAN :
4047322790901Category :
Valves Electropneumatically OperatedWeight :
0.01 kgRIEGLER 2x3/2-way valve for pneumatic control, max. 10 bar, G 1/4 - Type 517.232.14.NO.24D
The RIEGLER 2x3/2-way valve, electropneumatic, monostable, G 1/4, NO, 24 V DC controls the direction of the compressed air flow for targeted movement sequences. with NBR seals. The operating pressure range is 2.5 bar to 10 bar. The permissible medium temperature is between -10 °C and 60 °C. G 1/4 connection thread - suitable for common industry standards. Suitable for filtered compressed air with or without lubrication. If lubricated, then continuous. Operating voltage 24 V DC. Precise directional control for defined movement sequences.
Field of application
Typical areas of application: Pneumatic controls and mechanical engineering.
| Execution | electropneumatic |
| Control air supply | internal |
| Symbol | 64 |
| Scope of delivery | with plug and coil |
| Function | 2x3/2 NO |
| Series | Series 70 |
| Flow rate measurement 1 | Flow rate at 6 bar and ∆p 0.5 bar |
| Flow rate measurement 2 | Flow rate at 6 bar and Δp 1.0 bar |
| Flow 2 | 1100 Nl/min |
| Flow 1 | 750 Nl/min |
| Actuation | monostable |
| DN | 8 |
| Ambient temperature min. | -10 °C |
| Medium temperature min. | -10 °C |
| Max. operating pressure | 10 bar |
| Operating pressure min. | 2.5 bar |
| Tension | 24 V DC |
| Ambient temperature max. | 50 °C |
| Medium temperature max. | 60 °C |
| Connection | G 1/4 |
| Medium | Filtered compressed air with or without lubrication. If lubricated, then continuous. |
| Sealing material | NBR |
| Class name | PLUS |
| Manual override | resting |
Maintenance, wear and spare parts
| Product | Price | ||
|---|---|---|---|
![[147142] RIEGLER 2x3/2-way valve, electropneumatic, monostable, G 1/4, NO](/web/image/product.template/284084/image_128/%5B147142%5D%20RIEGLER%202x3-2-way%20valve%2C%20electropneumatic%2C%20monostable%2C%20G%201-4%2C%20NO?unique=1ce8a7f)
|
Typennummer: 7020023200 |
136.62 € | |
![[117313] RIEGLER Device plug, 22 mm, type B](/web/image/product.template/274839/image_128/%5B117313%5D%20RIEGLER%20Device%20plug%2C%2022%20mm%2C%20type%20B?unique=4bd6d96)
|
Type number: 1920.9P |
1.48 € | |
![[118632] RIEGLER Solenoid coil, 22 mm x Ø 8 mm, 24 V DC, 2 W](/web/image/product.template/275048/image_128/%5B118632%5D%20RIEGLER%20Solenoid%20coil%2C%2022%20mm%20x%20%C3%98%208%20mm%2C%2024%20V%20DC%2C%202%20W?unique=0560891)
|
Type number: 400-514-42 |
9.87 € | |
