RIEGLER Silencer, Stainless steel, flat tpye, M5, AF 8
Typennummer: SD5ESFL
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Silencer for noise protection, max. 15 bar, M5 - type SD5ESFL
The RIEGLER silencer, stainless steel, flat, M5, SW 8 significantly reduces the blow-off noise of pneumatic valves and cylinders. Designed for a maximum operating pressure of 15 bar. The operating temperature is between -10 °C and 250 °C. M5 connection thread - suitable for common industry standards. Significant noise reduction for improved occupational safety.
Field of application
Typical areas of application: Noise reduction on valves and exhaust air openings.
| Max. operating pressure | 15 bar |
| Operating temperature min. | -10 °C |
| Operating temperature max. | 250 °C |
| Thread | M5 |
| SW | 8 mm |
| A | 5 mm |
| B | 11.5 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Class name | STAINLESS STEEL |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[156489] RIEGLER Silencer, Stainless steel, flat tpye, G 1/2, AF 24](/web/image/product.template/213298/image_128/%5B156489%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%201-2%2C%20AF%2024?unique=3f08e73)
|
Typennummer: SD12ESFL |
14.01 € | |
![[156487] RIEGLER Silencer, Stainless steel, flat tpye, G 1/4, AF 16](/web/image/product.template/213296/image_128/%5B156487%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%201-4%2C%20AF%2016?unique=8d1f1c2)
|
Typennummer: SD14ESFL |
6.65 € | |
![[156486] RIEGLER Silencer, Stainless steel, flat tpye, G 1/8, AF 13](/web/image/product.template/213295/image_128/%5B156486%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%201-8%2C%20AF%2013?unique=9774803)
|
Typennummer: SD18ESFL |
4.15 € | |
![[156491] RIEGLER Silencer, Stainless steel, flat tpye, G 1, AF 36](/web/image/product.template/213300/image_128/%5B156491%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%201%2C%20AF%2036?unique=8c0378e)
|
Typennummer: SD1ESFL |
37.85 € | |
![[156490] RIEGLER Silencer, Stainless steel, flat tpye, G 3/4, AF 30](/web/image/product.template/213299/image_128/%5B156490%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%203-4%2C%20AF%2030?unique=f24b331)
|
Typennummer: SD34ESFL |
23.93 € | |
![[156488] RIEGLER Silencer, Stainless steel, flat tpye, G 3/8, AF 19](/web/image/product.template/213297/image_128/%5B156488%5D%20RIEGLER%20Silencer%2C%20Stainless%20steel%2C%20flat%20tpye%2C%20G%203-8%2C%20AF%2019?unique=402447f)
|
