KAESER Activated carbon adsorber model ACT 140
Volume flow: 14 m³/min | Compressed air connection: R 2
KAESER KOMPRESSOREN, a family-owned company, has been one of the world's leading manufacturers and suppliers of compressed air products and services since 1919
Product no. :
902727.0Category :
Activated Carbon AdsorbersWeight :
330.00 kgDelivery area :
GermanyKAESER ACT activated carbon adsorbers provide technically oil-free and odorless compressed air for continuous applications. They achieve residual oil contents of class 1 in accordance with ISO 8573-1 and protect sensitive production processes. With an oil vapor indicator, they guarantee a service life of up to 12,000 full-load hours or 5 years and are economical thanks to their low pressure loss.
| Volume flow (m³/min) | 14 |
| Pressure loss (bar) | 0,10 |
| Min. overpressure (bar) | 4 |
| Max. Overpressure (bar) | 16 |
| Min. ambient temperature (°C) | +2 |
| Max. Ambient temperature (°C) | +45 |
| Volume of compressed air tank (litres) | 205 |
| Width (mm) | 550 |
| Depth (mm) | 750 |
| Height (mm) | 2000 |
| Compressed air connection | R 2 |
| Min. inlet temperature compressed air (°C) | +2 |
| Max. Compressed air inlet temperature (°C) | +55 |
Accessoires and suitable extensions
| Product | Price | ||
|---|---|---|---|
![[102131.10701] KAESER Filter Dust model F142KD G 2"](/web/image/product.template/262339/image_128/%5B102131.10701%5D%20KAESER%20Filter%20Dust%20model%20F142KD%20G%202%22?unique=3f88f88)
|
Volume flow: 14.20 m³/min |
1,505.65 € | |
![[102132.20741] KAESER Filter Extra model F142KE G 2", ECO-DRAIN 31F](/web/image/product.template/262342/image_128/%5B102132.20741%5D%20KAESER%20Filter%20Extra%20model%20F142KE%20G%202%22%2C%20ECO-DRAIN%2031F?unique=3f88f88)
|
Volume flow: 14.20 m³/min | Residual aerosol content at outlet: < 0.1 mg/m³ |
1,811.78 € | |
![[920026.2] KAESER Pressure maintenance system Model DHS4.0 50G G2" PS16](/web/image/product.template/102679/image_128/%5B920026.2%5D%20KAESER%20Pressure%20maintenance%20system%20Model%20DHS4.0%2050G%20G2%22%20PS16?unique=977d5e0)
|
DHS 4.0 Electronic Pressure Maintenance System | 2" G | Ball Valve | 16 bar | Pulse Width Modulation | SIGMA NETWORK |
3,445.05 € | |
