RIEGLER Distributor »FUTURA«, Size 2 G 1/2, Outlets 2xG 3/8, G 1/4, G 1/2
Type number: FU 944
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER FUTURA" manifold made of PA66 GF60, for compressed air preparation, G 1/2 - type FU 944
The RIEGLER "FUTURA" manifold, BG 2, G 1/2, outlets 2xG 3/8, 1x G 1/4, G 1/2 expands maintenance systems modularly with additional functions. The housing is made of PA66 GF60. The maximum inlet pressure is 16 bar. The temperature range is between -10 °C and 50 °C. Connection thread G 1/2 - suitable for common industry standards. Suitable for compressed air, neutral gases. The flow rate is 7250 l/min (at P1 = 6 bar and pressure drop Δp = 1 bar). Seamless integration into existing systems.
Field of application
Typical areas of application: Modular compressed air treatment lines.
| Inlet pressure max. | 16 bar |
| Temperature range min. | -10 °C |
| Temperature range max. | 50 °C |
| Medium | Compressed air, neutral gases |
| Housing | PA66 GF60 |
| Connection thread | Material zinc die-cast |
| Flow rate measurement | at P<sub>1</sub> = 6 bar and pressure drop Î"<sub>p</sub> = 1 bar |
| Series | FUTURA |
| Thread | G 1/2 |
| Flow rate | 7250 l/min |
| Departure | 2 x G 3/8, 1 x G 1/4, 1 x G 1/2 |
| BG | 2 |
| A | 63 mm |
| B | 80.5 mm |
| C | 43 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS-No. |
| RoHS material information | RoHS compliant |
| RoHS Directive | 2011/65/EU, 2015/863/EU, 2018/741/EU |
| RoHS Article of the Directive | no entry |
| Share of SVHC substance in % for RoHS | 0 |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Proportion of SVHC substance in SCIP | no SVHC substance contained |
| Material identification | none |
| Theme shop | SAFETY |
| Class name | MAX |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[100274] RIEGLER Distributor »FUTURA«, Size 1, G 1/4, Outlets 3 x G 1/4](/web/image/product.template/132842/image_128/%5B100274%5D%20RIEGLER%20Distributor%20%C2%BBFUTURA%C2%AB%2C%20Size%201%2C%20G%201-4%2C%20Outlets%203%20x%20G%201-4?unique=0f275cc)
|
Type number: FU 941 |
16.86 € | |
![[100275] RIEGLER Distributor »FUTURA«, Size 1, G 3/8, Outlets 3 x G 1/4](/web/image/product.template/132843/image_128/%5B100275%5D%20RIEGLER%20Distributor%20%C2%BBFUTURA%C2%AB%2C%20Size%201%2C%20G%203-8%2C%20Outlets%203%20x%20G%201-4?unique=81e7727)
|
Type number: FU 942 |
16.86 € | |
![[100276] RIEGLER Distributor »FUTURA«, Size 2 G 3/8, Outlets 2xG 3/8, G 1/4, G 1/2](/web/image/product.template/132844/image_128/%5B100276%5D%20RIEGLER%20Distributor%20%C2%BBFUTURA%C2%AB%2C%20Size%202%20G%203-8%2C%20Outlets%202xG%203-8%2C%20G%201-4%2C%20G%201-2?unique=f8b223a)
|
Type number: FU 943 |
20.94 € | |
![[100279] RIEGLER Distributor »FUTURA«, Size 4, G 1, Outlets 2 x G 3/4](/web/image/product.template/139714/image_128/%5B100279%5D%20RIEGLER%20Distributor%20%C2%BBFUTURA%C2%AB%2C%20Size%204%2C%20G%201%2C%20Outlets%202%20x%20G%203-4?unique=5fd1454)
|
Type number: FU 946 |
60.79 € | |
![[100278] RIEGLER Distributor »FUTURA«, Size 4, G 3/4, Outlets 2 x G 3/4](/web/image/product.template/138956/image_128/%5B100278%5D%20RIEGLER%20Distributor%20%C2%BBFUTURA%C2%AB%2C%20Size%204%2C%20G%203-4%2C%20Outlets%202%20x%20G%203-4?unique=167ee0e)
|
