RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-2.5 bar/36 psi

https://www.filcom-technik.de/web/image/product.template/201058/image_1920?unique=635ee05

Type number: 804-CDE

23.15 € 23.150000000000002 EUR 23.15 € VAT Included

27.02 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

116325

EAN :

4047322177054

Category :

Glycerine-Filled Pressure Gauges

Weight :

0.24 kg

Glycerin mano. "pressure line", stainless steel housing, connection rear center, G 1/4, grade 1.6, measuring range 0 - 2.5 bar/36 psi, Ø 63

Housing Stainless steel 1.4301
Medium temperature min. -20 °C
Medium temperature max. 60 °C
Ambient temperature min. -20 °C
Ambient temperature max. 60 °C
Measuring element Brass
Pointer movement Brass
Viewing window Glass
Measuring range min. bar 0
Measuring range max. bar 0
Diameter 63 mm
Graduation value in the bar range 0.1 bar
Execution Bourdon tube pressure gauge with glycerine filling
Connection G 1/4
Quality class 45444
Connection position rear, centric
Class name EASY
Process connection material Copper alloy
