RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-60 bar/850 psi
Type number: 811-CDE
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
116332EAN :
4047322177177Category :
Glycerine-Filled Pressure GaugesWeight :
0.25 kgGlycerine press. gauge »pressure line« Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0-60 bar/850 psi, Ø 63
| Housing | Stainless steel 1.4301 |
| Medium temperature min. | -20 °C |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Brass |
| Pointer movement | Brass |
| Viewing window | Glass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 60 |
| Diameter | 63 mm |
| Graduation value in the bar range | 2 bar |
| Execution | Bourdon tube pressure gauge with glycerine filling |
| Connection | G 1/4 |
| Quality class | 45444 |
| Connection position | rear, centric |
| Class name | EASY |
| Process connection material | Copper alloy |
