RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-400bar/6000 psi

Price:

25.10 €

English (US)
  2. Shop
  3. Glycerine-Filled Pressure Gauges
  4. RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-400bar/6000 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-2.5 bar/36 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-2.5 bar/36 psi
23.15 € 23.15 €
RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-40 bar/600 psi
RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-40 bar/600 psi
23.15 € 23.15 €

RIEGLER Glycerine pressure gauge »pressure line« G 1/4, 0-400bar/6000 psi

https://www.filcom-technik.de/web/image/product.template/201069/image_1920?unique=6ac7f8b

Type number: 815-CDE

25.10 € 25.1 EUR 25.10 € VAT Included

29.29 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

116336

EAN :

4047322177245

Category :

Glycerine-Filled Pressure Gauges

Weight :

0.24 kg

Glycerin mano. "pressure line", stainless steel housing, connection rear center, G 1/4, grade 1.6, measuring range 0-400.0 bar/6000 psi, Ø63

Housing Stainless steel 1.4301
Medium temperature min. -20 °C
Medium temperature max. 60 °C
Ambient temperature min. -20 °C
Ambient temperature max. 60 °C
Measuring element Brass
Pointer movement Brass
Viewing window Glass
Measuring range min. bar 0
Measuring range max. bar 400
Diameter 63 mm
Graduation value in the bar range 10 bar
Execution Bourdon tube pressure gauge with glycerine filling
Connection G 1/4
Quality class 45444
Connection position rear, centric
Class name EASY
Process connection material Copper alloy
