RIEGLER Captive swivel safety coupling I.D. 6, ISO 6150 C, G 1/2 IT, red
Type number: 426.03-DREH-R
EAN: 4047322565110
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
141848EAN :
4047322565110Category :
Non-Interchangeable Quick-Lock CouplingsWeight :
0.10 kgUnmistakable rotary safety coupling NW 6, ISO 6150 C, steel, 2-stage, G 1/2 female thread, red, max. 25 bar, temp. -15 °C to 200 °C
| Temperature range min. | -15 °C |
| Temperature range max. | 200 °C |
| Housing | Steel, QPQ treated |
| Sealing material | FKM |
| Flow rate measurement | at 6 bar and Î"<sub>p </sub>= 0.5 bar |
| Flow rate | 630 l/min (air) |
| Spring | Stainless steel |
| Sleeve | Galvanized steel, painted in colour |
| Threaded piece | Galvanized steel |
| Valve | Polyphenylene sulfide (PPS) |
| Operating pressure | max. 25 bar / max. 16 bar when engaging/disengaging |
| SW | 24 mm |
| Colour | red |
| NW | 6 |
| Length | 67 mm |
| Connection | G 1/2 IG |
| Connector profile | according to ISO 6150 C |
| Class name | PLUS |
