RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 230 V AC

Price:

128.65 €

English (US)
  2. Shop
  3. Valves Electropneumatically Operated
  4. RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 230 V AC
RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 12 V DC
RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 12 V DC
128.65 € 128.65 €
RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 24 V AC
RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 24 V AC
128.65 € 128.65 €

RIEGLER 2x3/2-way valve, elpn, ext. control, mono, G 1/8, NC, 230 V AC

https://www.filcom-technik.de/web/image/product.template/284300/image_1920?unique=ed73e72

Typennummer: 517.232.18.E.NC.230A

128.65 € 128.65 EUR 128.65 € VAT Included

150.14 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

147420

EAN :

4047322791311

Category :

Valves Electropneumatically Operated

Weight :

0.01 kg

2x3/2-way valve, electropneumatic, ext. control, mono, G 1/8, NC, 230 V AC, 50/60 Hz, p= vacuum?10 bar, control pressure 2.5?10 bar, aluminum

Execution electropneumatic
Control air supply external
Tension 230 V AC
Symbol 68
Scope of delivery with plug and coil
Function 2x3/2 NC
Frequency 50/60 Hz
Pilot air connection M5
Series Series 70
Flow rate measurement 1 Flow rate at 6 bar and ∆p 0.5 bar
Flow rate measurement 2 Flow rate at 6 bar and Δp 1.0 bar
Flow 2 550 Nl/min
Flow 1 400 Nl/min
Actuation monostable
DN 5
Operating pressure min. -0.99 bar
Ambient temperature min. -10 °C
Medium temperature min. -10 °C
Control pressure max. 10 bar
Max. operating pressure 10 bar
Control pressure min. 2.5 bar
Ambient temperature max. 50 °C
Medium temperature max. 60 °C
Connection G 1/8
Medium Filtered compressed air with or without lubrication. If lubricated, then continuous.
Sealing material NBR
Class name PLUS
Manual override resting

Maintenance, wear and spare parts

Product Price
[147149] RIEGLER 2x3/2-way valve, electropneumatic, ext. control, mono, G 1/8, NC

Typennummer: 7010023400

 117.32 €
[117313] RIEGLER Device plug, 22 mm, type B

Type number: 1920.9P

 1.48 €
[118630] RIEGLER Solenoid coil, 22 mm x Ø 8 mm, 230 V AC, 50/60 Hz, 3.5 VA

Type number: 400-514-17

 9.87 €
