RIEGLER Plug nipple »Blue Series«, plug nipple 10 mm
Type number: 178.010
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Stecknippel »Blaue Serie«, Stecknippel 10 mm, pmax kurzzeitig 15 bar, Kunststoff
| Temperature range min. | -20 °C |
| Temperature range max. | 80 °C |
| Medium | Compressed air |
| Series | Blue series |
| Working pressure min. | -0.95 bar |
| Working pressure max. | 10 bar |
| Material | Plastic |
| Area of application | Compressed air systems, automotive, packaging industry, vacuum |
| Plug nipple | 10 mm |
| L1 | 40.2 mm |
| REACH SVHC1 Substance Name | no |
| CAS No. SVHC 1 | none CAS No. |
| RoHS material information | RoHS compliant |
| Exception | no exception |
| REACH Info | no SVHC substance contained |
| Share of SVHC SCIP | no SVHC substance |
| Class name | EASY |
| Working pressure max. short-term | 15 bar |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[109918] RIEGLER Plug nipple »Blue Series«, plug nipple 12 mm](/web/image/product.template/178831/image_128/%5B109918%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%2012%20mm?unique=8914fc3)
|
Type number: 178.012 |
1.14 € | |
![[135803] RIEGLER Plug nipple »Blue Series«, plug nipple 16 mm](/web/image/product.template/206181/image_128/%5B135803%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%2016%20mm?unique=f70c983)
|
Type number: 178.016 |
1.63 € | |
![[109914] RIEGLER Plug nipple »Blue Series«, plug nipple 4 mm](/web/image/product.template/178827/image_128/%5B109914%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%204%20mm?unique=78c1b51)
|
Type number: 178.004 |
0.70 € | |
![[109915] RIEGLER Plug nipple »Blue Series«, plug nipple 6 mm](/web/image/product.template/178828/image_128/%5B109915%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%206%20mm?unique=54688e6)
|
Type number: 178.006 |
0.80 € | |
![[109916] RIEGLER Plug nipple »Blue Series«, plug nipple 8 mm](/web/image/product.template/178829/image_128/%5B109916%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%208%20mm?unique=77e1e9a)
|
Type number: 178.008 |
0.89 € | |
