RIEGLER Plug nipple »Blue Series«, plug nipple 16 mm
Type number: 178.016
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Plug-in nipple "Blue series" made of plastic, for pneumatic installation, max. 10 bar - Type 178.016
The RIEGLER plug-in nipple "Blue series", plug-in nipple 16 mm enables the quick, tool-free connection of compressed air lines - securely sealing and immediately loadable. The housing is made of plastic. The operating pressure range is -0.95 bar to 10 bar. The temperature range is between -20 °C and 80 °C. Suitable for compressed air. Quick assembly without tools - saves time during installation and conversion.
Field of application
Typical areas of application: Pneumatic installations, machine piping and automation technology.
| Temperature range min. | -20 °C |
| Temperature range max. | 80 °C |
| Medium | Compressed air |
| Series | Blue series |
| Working pressure min. | -0.95 bar |
| Working pressure max. | 10 bar |
| Material | Plastic |
| Area of application | Compressed air systems, automotive, packaging industry, vacuum |
| Plug nipple | 16 mm |
| L1 | 56 mm |
| Class name | EASY |
| Working pressure max. short-term | 15 bar |
Variants / Alternatives
| Product | Price | ||
|---|---|---|---|
![[109917] RIEGLER Plug nipple »Blue Series«, plug nipple 10 mm](/web/image/product.template/178830/image_128/%5B109917%5D%20RIEGLER%20Plug%20nipple%20%C2%BBBlue%20Series%C2%AB%2C%20plug%20nipple%2010%20mm?unique=0fcd1bc)
|
