RIEGLER Fine pressure gauge, G 1/2 radial bottom, 0 - 60.0 bar, Ø 160

https://www.filcom-technik.de/web/image/product.template/276079/image_1920?unique=8a97eae

Typennummer: 1169-R

309.05 € 309.05 EUR 309.05 € VAT Included

360.70 € VAT Included


Price tiers visible after login - register now and get your benefits!

  • Brand

This combination does not exist.


Price Tiers

from 110 € free shipping Details shipping costs
Contact Us
Riegler

Riegler

The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years

Product no. :

199327

EAN :

4047322699846

Category :

Precision Pressure Gauges

Weight :

0.91 kg

Fine pressure gauge, radial bottom connection, G 1/2, grade 0.6, scale graduation 0.500, measuring range 0 - 60.0 bar, Ø 160

Housing CrNi steel
Medium temperature max. 60 °C
Ambient temperature min. -20 °C
Ambient temperature max. 60 °C
Measuring element Copper alloy
Pointer movement Brass
Measuring range min. bar 0
Measuring range max. bar 60
Diameter 160 mm
Graduation value in the bar range 0.5 bar
Connection G 1/2
Quality class 0.6
Lower / Upper measuring range limit Overpressure
Ring CrNi steel
Connection position radial bottom
Class name PLUS
Viewing window Plastic (PMMA)
Process connection Brass, radial bottom, G1/2B - SW22 (EN 837-1/7.3)
Process connection material Brass
