RIEGLER Precision pressure gauge, G 1/2 radial bottom, 0 - 4.0 bar, Ø 160
Typennummer: 1163-R
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
Precision pressure gauge, radial bottom connection, G 1/2, grade 0.6, scale graduation 0.020, measuring range 0 - 4.0 bar, Ø 160
| Housing | CrNi steel |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Brass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 4 |
| Diameter | 160 mm |
| Graduation value in the bar range | 0.02 bar |
| Connection | G 1/2 |
| Quality class | 0.6 |
| Lower / Upper measuring range limit | Overpressure |
| Ring | CrNi steel |
| Connection position | radial bottom |
| Class name | PLUS |
| Viewing window | Plastic (PMMA) |
| Process connection | Brass, radial bottom, G1/2B - SW22 (EN 837-1/7.3) |
| Process connection material | Brass |
