RIEGLER Fine pressure gauge, G 1/2 radial bottom, 0 - 25.0 bar, Ø 160
Part Number: 1167-R
The family-owned company RIEGLER & Co. KG in Bad Urach has stood for innovative, high-quality solutions in the field of compressed air and pneumatic components for over 80 years
RIEGLER Precision pressure gauge made of stainless steel, for pressure measurement, G 1/2 - Type 1167-R
The RIEGLER precision pressure gauge, G 1/2 radial bottom, 0 - 25.0 bar, Ø 160 indicates the current system pressure reliably and precisely. The housing is made of stainless steel. The ambient temperature is between -20 °C and 60 °C. G 1/2 connection thread - suitable for common industry standards. Reliable pressure indicator for safe system control.
Field of application
Typical areas of application: Pressure monitoring in compressed air, hydraulic and process systems.
| Housing | CrNi steel |
| Medium temperature max. | 60 °C |
| Ambient temperature min. | -20 °C |
| Ambient temperature max. | 60 °C |
| Measuring element | Copper alloy |
| Pointer movement | Brass |
| Measuring range min. bar | 0 |
| Measuring range max. bar | 25 |
| Diameter | 160 mm |
| Graduation value in the bar range | 0.2 bar |
| Connection | G 1/2 |
| Quality class | 0.6 |
| Lower / Upper measuring range limit | Overpressure |
| Ring | CrNi steel |
| Connection position | radial bottom |
| Class name | PLUS |
| Viewing window | Plastic (PMMA) |
| Process connection | Brass, radial bottom, G1/2B - SW22 (EN 837-1/7.3) |
| Process connection material | Brass |
