RIEGLER 2x3/2-way valve, electropneumatic, monostable, G 1/4, NC-NO
Type number: 7020023300
EAN: 4047322788717
RIEGLER & Co. KG in Bad Urach is a respected company known for its innovative approaches, top-notch product quality, and dedicated customer service. For over 80 years, this family-owned business has evolved into a leading provider of components for compressed air and pneumatics, as well as customized system solutions.
Product no. :
147146EAN :
4047322788717Category :
Valves Electropneumatically OperatedWeight :
0.26 kgFlow meter "FLUX", BG 1, 0?2000 Nl/min, G 1/2, p1 = 0?10 bar, T = 0?50 °C, 12?24 V DC, PNP, with display/pressure sensor/WiFi
| Execution | electropneumatic |
| Control air supply | internal |
| Tension | ohne Spannung |
| Symbol | 66 |
| Scope of delivery | without plug and coil |
| Function | 2x3/2 NC-NO |
| Series | Series 70 |
| Flow rate measurement 1 | Flow rate at 6 bar and ∆p 0.5 bar |
| Flow rate measurement 2 | Flow rate at 6 bar and Δp 1.0 bar |
| REACH Info | contains SVHC substance |
| RoHS material information | Rohs compliant |
| REACH SVHC1 Substance Name | Lead |
| Flow_2 | 1100 Nl/min |
| Flow_1 | 750 Nl/min |
| Actuation | monostable |
| DN | 8 |
| Ambient temperature min. | -10 °C |
| Medium temperature min. | -10 °C |
| Max. operating pressure | 10 bar |
| Operating pressure min. | 2.5 bar |
| Ambient temperature max. | 60 °C |
| Medium temperature max. | 60 °C |
| CAS No. SVHC 1 | 7439-92-1 |
| Connection | G 1/4 |
| Medium | Filtered compressed air with or without lubrication. If lubricated, then continuous. |
| Sealing material | NBR |
| Class name | PLUS |
| Manual override | resting |
